Round Bar Shape Electric Arc Furnace Electrodes High Oxidation Resistance

Round Bar Shape Electric Arc Furnace Electrodes High Oxidation Resistance
Round Bar Shape Electric Arc Furnace Electrodes High Oxidation Resistance Round Bar Shape Electric Arc Furnace Electrodes High Oxidation Resistance

Large Image :  Round Bar Shape Electric Arc Furnace Electrodes High Oxidation Resistance

Product Details:
Place of Origin: China
Brand Name: Hopes
Certification: CCIC
Model Number: UHP
Payment & Shipping Terms:
Minimum Order Quantity: 20mt
Packaging Details: in wooden pallets or wooden cases
Delivery Time: 25 working days
Supply Ability: 1000mt/month

Round Bar Shape Electric Arc Furnace Electrodes High Oxidation Resistance

Description
Color: Black Shape: Round Bar
Application: Industry, Casting, Metallurgy & Foundry, Steel Making And Other, Metallurgy
High Light:

uhp graphite electrode

,

electric arc furnace electrodes

ultra high power graphite electrode uhp for arc furnaces with factory price



  1. Product detail

    Graphite electrode raw materials use the domestic petroleum coke and pitch coke. HP grade graphite electrode add 30% imported needle coke. UHP graphite electrode use more than 80% imported needle coke. They are widely used in electric arc furnace, ladle furnace for the production of alloy steel,metal and nonmetallic materials. They are characterized by low resistivity, good electric and thermal conductivity, high resistance to oxidation and thermal shock, high mechanical strength, etc

  2.

Properties
Unit
UHP
HP
RP
300-600mm
650-800mm
300-800mm
300-800mm
Electric resistivity
Electrode
μΩm
4.8-5.8
4.6-5.8
5.8-6.6
7.8-8.8
Nipple
3.8-4.5
3.8-4.5
4.2-5.0
5.0-6.5
Flexural strength
Electrode
Mpa
10.0-14.0
10.0-14.0
10.0-13.0
7.0-12.0
Nipple
20.0-26.0
22.0-26.0
18.0-22.0
15.0-20.0
Young's modulus
Electrode
Gpa
9.0-13.0
10.0-14.0
8.0-12.0
7.0-9.3
Nipple
15.0-18.0
15.0-18.0
14.0-16.0
12.0-14.0
Bulk density
Electrode
≥g/cm3
1.68-1.74
1.70-1.74
1.62-1.66
1.53-1.56
Nipple
1.77-1.82
1.78-1.84
1.74-1.80
1.70-1.74
CTE(100-600℃)
Electrode
x10-6/℃
1.1-1.4
1.1-1.4
1.6-1.9
2.2-2.6
Nipple
0.9-1.2
0.9-1.2
1.1-1.4
2.0-2.5
Ash
0.3
0.3
0.3
0.5
